Installation Instructions

FIRST, READ INSTRUCTIONS CAREFULLY, THEN PROCEED TO INSTALL VALVE BODY BY FOLLOWING
EACH STEP INDIVIDUALLY.

Valve Body

24142A Valve Body 1965-Up (Includes Late 2-3 Accumulator piston installed.)

Kit Includes:

1 -

24115

Special Valve Body Spacer Plate

1 -

24117

Expansion Plug (See STEP #7)

1 -

24148C Pan Gasket

1 -

24149

Spacer to Valve Body Gasket (Small) OEM#8623561

1 -

24150

Spacer to Case Gasket (Large) OEM#8623563

1 -

24122

Modulator Replacement Plug

1 - 24982

2-3 Accum. Piston 1965-70

STEP #1:

Transmission should be cool before installing. Be sure vehicle is secure to prevent rolling.
Drain oil by carefully removing transmission pan bolts. Recommend leaving a couple of bolts
partially attached until some of the oil has drained.

STEP #2:

Remove transmission filter. If 1968 or newer model, remove retaining bolt, hold pipe that filter
is connected to and then pull filter off.

STEP #3:

Before loosening valve body, note how the gear selector lever connects to the manual control
valve in the valve body. Fig. #2.

STEP #4:

Remove bolts from valve body and then carefully remove governor tubes and valve body
together. Avoid bending governor tubes. If 1970 or newer model, disconnect white wire

from the valve body. Also, be sure the manual control valve doesn’t slide out.

Note: Sometimes the Intermediate Servo will fall out when removing the valve body, Fig. #3.

STEP #5:

Remove the two bolts holding the downshift solenoid and valve body spacer plate. Make sure
you support the spacer plate with your hand. Lower the plate with steel balls carefully.

STEP #6:

If transmission is being overhauled when installing the valve body, the following steps will
enhance the 2-3 shift. However, if unit is not being overhauled, DO NOT DO STEP #7.

STEP #7:

Remove center seal from direct clutch drum, Fig. #2A. Install expansion plug #24117 as
shown in Fig. #2A. This expansion plug must be driven in until it is flush with case or deeper.

1535 Owens Road, Jacksonville, FL 32218

Phone (904) 741-4850

*** FAX (904) 741-4853

www.turboaction.com

CHEETAH Manual ProStreet Valve Body -

PRN321

Stock Pattern

Part #24142A - Turbo Hydro “375” & “400” 1965-Up
