Maintenance
21 F232137 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
6. Clean customer-supplied steam filter, where
applicable. Refer to Figure 13.
a. Turn off steam supply and allow time for the
valve to cool.
b. Unscrew Cap.
c. Remove Element and clean.
d. Replace Element and Cap.
7. For variable speed and F-speed models only,
measure the out-of-balance switch gap setting
and adjust it as needed. The switch gap settings
are listed in the Installation manual, which is
supplied with the machine.
8. Check the bearing mounting bolts to make sure
they are torqued properly. Refer to Table 8 for
specifications.
H042I
1 Cap
2 Filter Element
Figure 13
H042I
1
2
Machine
Capacity
Bearing Torque
18-25 All 75 ft.-lbs.
27-60 All 105 ft.-lbs.
80 Front 200 ft.-lbs.
80 Rear 97 ft.-lbs.
125 Front 500 ft.-lbs.
125 Rear 140 ft.-lbs.
Table 8
