36 MulTView™
MulTView™
If you have an All-In-Wonder® X1800 Series Series card and an ATI TV
Wonder™ PCI card installed in the same system, MulTView™ lets you
watch a different channel in a secondary video window. You can record
video from your All-In-Wonder® X1800 Series while you watch another
channel on the TV Wonder™. The secondary window can be in the
following locations:
CRT display +
CRT display VGA connector +
DVI-I connector
with DVI-I-to-VGA
adapter The DVI-I connector can support a
CRT display using the DVI-I-to-VGA
adapter
CRT display +
DFP display +
TV VGA connector +
DVI-I connector +
S-Video Out The TV display will “clone” the image
of one of the other two displays
CRT display +
DFP display +
HDTV VGA connector +
DVI-I connector +
HDTV (YPrPb)
output cable UNSUPPORTED CONFIGURATION
CRT display +
CRT display +
TV VGA connector +
DVI-I connector
with DVI-I-to-VGA
adapter +
S-Video Out
CRT display +
CRT display +
HDTV VGA connector +
DVI-I connector
with DVI-I-to-VGA
adapter +
S-Video Out to
HDTV (YPrPb)
cable UNSUPPORTED CONFIGURATION
CRT display +
European TV SCART + VGA
Connector
DFP +
European TV SCART + DVI-I
European TV +
TV SCART + TV
(S-Video /
composite video) UNSUPPORTED CONFIGURATION
Display
Configuration Connector(s)
Used Comments
