14 Input and Output Adapters
Using the SCART Connector
SCART is an acronym for “Syndicat des Constructeurs d'Appareils
Radiorécepteurs et Téléviseurs”. SCART is an analog 21-pin connector
used mainly in Europe for transferring audio and video signals between
1
ATI input adapter used with earlier All-in-Wonder® products.
2
RF1 F-connector for cable TV input.
3
RF2 F-connector for cable FM radio input.
4
ATI input connector used with earlier All-in-Wonder® products.
5
S-Vide connector
6
Input / Output connector.
7
All-In-Wonder® X1800 card.
