34
To connect your monitors
1 Turn off your computer and monitors.
2 Plug the monitor cables into their appropriate connectors.
3 Turn on your monitors first, and then restart your computer so that
Windows® can detect the new hardware settings.
4 When the New Hardware Found Wizard appears, at the appropriate
prompt insert the ATI Installation CD to load the drivers for your All-
In-Wonder® X1800 card.
To set up a multi-monitor display
1 From the Start menu click Control Panel , then Display . Click the
Settings tab to access the basic multi-monitor configuration settings.
Note: ATI software provides many additional configuration features
that can be accessed by clicking the
Advanced button from the
Display Properties > Settings tab.
2 Select the Monitor icon identified by the number 2 .
3 Click Extend my Windows desktop onto this monitor .
4 Set the Screen Resolution and Color Quality as appropriate for the
second monitor. Click Apply or OK to apply these new values.
Connections and Adapters for the All-In-Wonder® X1800 Card
X Standard VGA Monitor Connector. To connect a VGA monitor
to the DVI-I connector, plug the supplied DVI-I-to-VGA adapter
into the DVI-I connector, then plug your monitor cable into the
adapter.
Y
DVI-I-to-VGA Adapter (if necessary).
Z
DVI-I Backplate Connection. To connect a flat panel, plug the
monitor’s DVI-I connector directly into the DVI-I connection.
[
Honda/VGA adapter (included): To connect a second VGA
monitor, plug the second monitor into the VGA connection on the
Honda/VGA adapter.
\
Honda backplate adapter connection: To enable a second
monitor and provide a connection for TV (S-Video), plug the
Honda/VGA adapter into the Honda backplate connection.
