4. Remove the oil filter from the valve body. Remove the detent spring

attaching the bolt and spring (4).

5. Use a pair of diagonal cutters to remove the shift lever retaining pin (5)

from the case. Loosen the 20mm nut on the inner end of the shift lever

and slide the lever out. Leave the throttle lever shaft and inner lever (6)

in place.

6. Slide the new shift lever into the case over the throttle lever shaft. The

arm should be pointed downwards. Engage the new shift lever (1)

with he inner shift lever (7) and install the nut. Install the shift lever

retaining pin back into its hold in the case and tap it in. Tighten the nut.

Check to see that the inner throttle lever (6) is properly located and that

the spring is in place. Check that the park operating rod (8) is in place.
