Wiring for ididit Steering Column
#1 Green Rear Brake Lights
#2 White/Blue Right Front Turn Signal
#3 Green/White Left Front Turn Signal
#4 Orange/Blue Right Rear Turn Signal
#5 Green/Orange Left Rear Turn Signal
#6 White/Red Hazzard Flasher
#7 Blue Turn Signal Flasher
#8 Yellow Horn
#9 Yellow/Blue Horn Ground
#10
*Included with the connector are new terminals for the car side if your originals are not usable or if you
have an aftermarket harness and do not have matching terminals.
3
Using All New Wiring Provided:
Included are male and female blocks along with the
necessary terminals and wiring diagram. You will have
to remove the pins from the original connector off the
car side of the harness and insert the pins into the back
side of the new block provided. Insert each terminal
completely until each one snaps into place. You can
verify it is secure by lightly tugging on it. You may need
to bend the locking tab back out slightly. Then you
will also install the new block on the column harness
matching color for color.
Wiring Installation:
1
2
3
4
5
6
7
8
9
10
