User can also perform zoom feature in details be selecting four options from the lower toolbar of the trace
window. Available options for zoom are: Horizontal & Vertical, Horizontal, Pan and None with Undo and Redo
selections.
Export as PDF:
Any trace window can be exported, printed and saved as a PDF document by selecting button from
the lower toolbar of the trace window. Exported trace file can be used for any report file or documentation.
Channel Control:
Select icon and a sidebar will appear on the right hand side of the software by default. This
allows you to change all related settings to control sensor channels. The Peak Power Analyzer software
has the capability of handing multiple control channels by selecting each individual from the drop down
list. Channel control setting is defined by several parameters as listed below:
