6
PARTS LIST
GOOSENECK FRAME ASSEMBLY
MODEL I-55 XL2
KEY NO. PART NO. DESCRIPTION
. A400B Gooseneck Frame
2. AFB-00054 Bolt, /2” NC x 3-/2” Lg.
3. AHF-00028 Fitting Grease 90° /8 NPT
4. A052A Pin, Frame Attachment, 2” OD x 8-/6” Long
5. A25006 Safety Link Pin
6. A23230-20 Travel Lock
7. AFB-00025 Bolt, 7/8”NC x 5” Lg. Grade 8
8. AFN-0009 Nut, 7/8”NC
9. 825 Lockwasher 7/8”
0. A4002 Cast Socket Half - Rear
. A4003 Cast Socket Half - Front w/Zerk Hole
2. A2206 Grease Zerk - Long Shank
3. A4039 Bushing, 2-3/8” OD x 2” Long
4. OPT-0000 Hitch Jack
GOOSENECK FRAME ASSEMBLY
Up to S.N. 21763
