23
KEY NO. PART NO. DESCRIPTION
1. A140H20 Barrel Assembly: 5” Bore
2. A400H06 O-Ring: 5” OD X 4-1/2” ID
3. A400H05 Back Up Washer: 5” OD X 4-1/2” ID
4. A140H21 Head Gland: 5”
5. ----- Set Screw: 3/8” NC
6. A140H19 Collar
7. A140H07 Shaft Seal: 2-1/2” ID X 3” OD OU-Cup
8. A140H08 Wiper Seal: 2-1/2” ID X 2-15/16” OD
9. 8602 Cotter Pin: 1/4” X 2”
10. A14033 Pin: 1-1/4” Dia. X 5” Lg.
11. A140H27 Shaft: 2-1/2” Dia.
12. A175H06 Spacer
13. A22H15 O-Ring: 1-1/2” x 1-3/4” OD
14. A140H22 Piston: 5”
15. A140H24 Piston Seal: 5” OD X 4-1/4” ID
16. A140H25 Wear Ring: 5” OD
17. AFN-00018 Lock Nut: 1-1/2” NF
18. A9024 Pin: 1-1/4” x 4-3/4”
A140H28 Packing Kit: Containing:
(1) A140H25 (1) A400H06
(1) A140H07 (1) A140H08
(1) A22H15 (1) A400H05
(1) A140H24
MODEL I-155 XL2
PUSHOFF CYLINDER 5 X 60”
PART NO. A560H114A
