Ashland I-155XL2 Ver 8-2006 User Manual
Page 24
24
KEY NO. PART NO.
DESCRIPTION
.
A2577-0
Barrel Weldment ()
2.
A2577-20
Shaft ()
3.
A2577-30
Piston ()
4.
A2577-3
Head ()
5.
A2576-32
Spacer ()
6.
A2575-33
/4” Nylock Nut ()
8.
A2577-40
Seal Kit ()
9.
A2575-35
Bearing
0.
A2575-36
Snap Ring
.
A2575-37
Grease Zerk ()
2.
A9024
Pin -/4 x 4-3/4 Lg
3.
A4033
Pin -/4 x 5 Lg
4.
AFP-0000
Cotter Pin /4 x 2
MODEL I-155 TS2
PUSHOFF CYLINDER 5 X 60”
PART NO. A125177
S.N. 21459 And Up
