Ashland I-155XL2 Ver 8-2006 - Manual (Page 13)

3
KEY NO. PART NO. DESCRIPTION
. AFB-0008 Bolt ” NC x 3” Long
2. A407 Ball Swivel
3. A402 Spindle, Weld on Blank
4. A23375 Pole w/20.5 x 25 Tires (opt’l)
A23422 Pole w/23.5 x 25 Tires (opt’l)
5. AFB-00052 Bolt, 5/6” x 3” Long
6. A409 Pin -3/4” x 7-3/8” Long (Up to July 2003)
A23232-07 Pin -3/4” x 9” Long ( After July 2003)
7. A75 Swivel Hitch, Double Lip (optional)
8. A750 Swivel Hitch Single Lip
9. 4505 Grease Fitting
0. A0048 Spindle Nut
. A0049A Lock Collar
2. A072 Nut with Lock Pin
3. 7430 Nut, 5/6” NC
4. AFW-00006 Lockwasher ”
A23232 Swivel Hitch Rebuild Kit, includes
items 6,5,6,7
5. A23232-3 Hitch: Yoke assembly
6. A23232-2A Swivel Block 4x4x3 (before serial #7805)
A23232-2 Swivel Block 4x6x3 (serial #7805 and above)
7. A23232- Hitch: Retaining Collar
B
A
PARTS LIST
POLE and AXLE ASSEMBLY
MODEL I-55 XL2
POLE and AXLE ASSEMBLY
