MODEL I-155 XL2
BOWL & FRAME ASSEMBLY
KEY NO.
PART NO.
DESCRIPTION
1.
A123309
Bowl and Frame, Model I-155
2.
AFB-00094
Flanged Bolt: 3/8 NC X 1”
3.
A10157
to S/N 20495: Cylinder Guard - Left Hand
A123309-77
from S/N 20496 to S/N 20749: Cylinder Guard - Left Hand
A123309-62L
S/N 20750 and above
4.
A10158
Cylinder Guard - Right Hand to S.N 20749
A123309-62R
S/N 20750 and above
7.
A123332L
Left Cutting Edge
8.
A123330SER
Center Cutting Edge, Serrated 1-1/8” x 12” x 63”
A123330
Center Cutting Edge, Straight 1-1/8” x 12” x 63”
PB9P-NC-088-0275 Plow Bolt: 7/8 NC X 2-3/4” -> 12 Required
9.
A123332R
Right Cutting Edge
10.
PB9P-NC-088-0275 Plow Bolt: 7/8 NC X 2-3/4” -> 6 Required
11.
AFB-0018
Bolt, 1” NC x 3” long, (5 per Blade Required)
12.
A123357
Bank Shaver/router bit Reversible, L & R
13.
AFN-00012
Nut: 1” NC (5 per Blade Required)
14.
AFN-00019
Nut: 7/8” NC -> 6 Required
15.
A125019
Grease Fitting 1/4 x 28.54 Long
16.
A125026
Bulkhead Nut
17.
A123309-89
Single Hole Tab
18.
A125022
18” Grease Line
