2
KEY NO. PART NO. DESCRIPTION
. A4022 Brace
2. AFN-00006 Nut: 3/4” NC
3. AFB-00037 Bolt: 3/4” NC x 2” Lg.
4. AFW-00002 Lockwasher: 3/4”
5. 800 Lockwasher: /2”
6. AFN-0005 Nut: /2” NC
7. A4023 Dirt Shield
8. AFB-0005 Bolt: /2” NC x -/2”
9. A6024 Pushoff Gate: Model I-50
0. A23306 To S.N. 20495: Roller: Rear Gate
0A A23307 To S.N. 20495 Bushing
0B. A23305A Pin: -/4 X 2-3/4” for Wear Pad
0C. A23353 Wear Pad
. AHF-00028 Grease Fitting: /8” NPT -90 degree
2. A6007A Pin: -/4” x 4-/8” Lg.
3. AFP-0000 Cotter Pin: /4 X 3-/2”
4. A063 Bushing: -3/4” OD x -/4” ID
5. A23459 V-Roller: 3-/2 OD X -3/4 ID
6. A23323-2 Pin: -/4 X 4 /8” Tab Head
7. 7036 Bolt: /2 NC X 2”
8. A063 Bushing: -3/4” OD x -/4” ID
9. A064 Roller: 4-/4 OD X -3/4 ID.
20. A23305A Pin: -/4 x 2-3/4” w/grease for Roller
2. 800 Lockwasher: /2”
22. AFB-00033 Bolt: /2 NC X 2-/2”
25. A2509 Grease Fitting /4 x 28.54 Long (4)
26. A25026 BulkHead Nut (4)
27. A23323-40 Double Hole Tab (2)
28. A2502 54” greaseline (2)
29. A2509 Grease Fitting /4 - 28 .54” long (4)
S.N. 2438 and Up
I-55XL2 Push Off Gate Assembly
