Table 1 Configuration Tab Fields (continued)
Description Field Group
HP 3PAR Management Plug-in and
Recovery Manager Software for VMware Secure service
vSphere uses a secure Web service (using
SSL certificates) securing all interactions
between the VMware components (vCenter
Server and vSphere clients) and HP 3PAR
Management Plug-in and Recovery
Manager Software for VMware vSphere.
The SSL certificate for HP 3PAR
Management Plug-in and Recovery
Manager Software for VMware vSphere
(provided by HP 3PAR) must be installed.
The trace file name. The default file name
is :\Program Files\ Log folder Debug
3PAR\Plug-In for Vmware
vSphere\Log .
Specifies the level of verbosity of the log
file. The default value is Low. Debug level
2. Modify the fields as necessary.
3. Click Verify.
The operating environment is examined and, if no configuration errors are reported, a dialog
appears indicating that the configuration has been completed successfully.
4. Click OK.
5. Click Save to save your changes.
Plug-in Registration
The Plug-in Registration option is used to register and unregister the HP 3PAR plug-in with the
vCenter Server is shown in (
Figure 18 (page 35) ).
Figure 18 Plug-in Registration
NOTE: You must be an Administrator of the vCenter Server for plug-in registration.
The fields available from the Plug-in Registration tab are shown in Table 2 (page 36) .
vCenter Plug-in Tab 35
