Value Specification
HP 72GB 15k SAS 2.5 HP DP HDD Disk drives (2)
HP FC1242Sr 4Gb PCI-E DC Host bus adapters (2)
12.7 mm SATA DVD kit DVD
Power supply specifications
The server is configured with two HP ProLiant 460 W power supplies. The following table lists the
specifications for one power supply.
Value Specification
Input requirements
100 to 120 VAC, 200 to 240 VAC Rated input voltage
50 Hz to 60 Hz Rated input frequency
5.5 A at 100 VAC
2.6 A at 200 VAC
Rated input current
526 W at 100V AC input
505 W at 200V AC input
Rated input power
1794 at 100V AC input
1725 at 200V AC input
BTUs per hour
Power supply output
460 W at 100V to 120V AC input
460 W at 200V to 240V AC input
Rated steady state power
460 W at 100V to 120V AC input
460 W at 200V to 240V AC input
Maximum peak power
Host bus adapter performance specifications
The FC1242SR DC HBA is a 4 Gb/s Fibre Channel PCIe HBA. The Fibre Channel controller of the
HBA incorporates a multifunction native PCIe core that is compliant to the PCIe Base Specification
1.0a and PCIe CEM Specification 1.0a. The supported physical PCIe connector is x4, x8, or x16.
The HBA has the following performance features:
• Auto-negotiation between 1, 2, or 4 Gb/s link attachments
• High performance Fibre Channel host bus adapter
• Full support for all Fibre Channel topologies: point-to-point, arbitrated loop, and fabric
• Full support for Fibre Channel Service Class 2 and Service Class 3
• Compliance with the PCIe Base and CEM 1.0a specifications:
