Status Description Item
Green = Normal
Off = One or more of the following conditions exists:
• AC power unavailable
• Power supply failed
• Power supply in standby mode
• Power supply exceeded current limit
Power supply 2 LED 10
Green = Normal
Off = One or more of the following conditions exists:
• AC power unavailable
• Power supply failed
• Power supply in standby mode
• Power supply exceeded current limit
Power supply 1 LED 11
Table 5 Post LED states for 4Gb HBAs
Activity Amber LED Green LED Yellow LED
Power off Off Off Off
Power on before or after firmware installa-
tion
On On On
Power on after firmware initialization Flashing Flashing Flashing
Firmware fault
Alternatively flash-
ing Alternatively flash-
ing Alternatively flash-
ing
Activity at 1 Gb/s Flashing Off Off
Activity at 2 Gb/s Off Flashing Off
Activity at 4 Gb/s Off Off Flashing
Beacon Flashing Off Flashing
HP Systems Insight Display LEDs
The HP Systems Insight Display LEDs represent the system board layout. The display provides status
for all internal LEDs and enables diagnosis with the access panel installed.
To view the LEDs, access the HP Systems Insight Display (see “ Access the HP Systems Insight
Display ” on page 18).
HP StorageWorks Virtualization Services Manager v2 server user guide 11
