INTRAC-305 OPERATION
© 2011 Advantech Wireless INTRAC-305 MANUAL - Issue 3.2 Page 25
3
X2 SETUP
X2 resolvers have a 1:2
gearbox on the input shaft
to provide extra resolution.
This screen allows the user
to resolve a +/- 180º
ambiguity in the displayed
main axes angles.
1
2
3
4
5
6
puts the antenna control system into
STANDBY mode and skips to the HOME
menu
skips to the Home (root) menu
sets the offset for the X2 resolver
clears the offset for the X2 resolver
(not used)
(not used)
Current Mode Tracking
Control State Local
Beac Freq 11.452000 GHz
Beac Level -10.05 dB
El Angle 25.37
Az Angle 210.50
Pol Angle 27.4
Standby
Home
Set
Offset
Function
Press EN to accept selection
Clear
Offset
X2 RESOLVER SETUP
Path HOME - FUNCTION - MENU KEY 6 (x4) - ENTER
or From Models or System Setup :-
CONFIG - MENU KEY 6 (x4) - ENTER
Note This funct ion is only available if the “Resolver Type” in
System Setup - Fitted Options has been set to “EG-01 Fitted”.
If the “Extended Az” in System Setup - Fitted Options has
been set to “Fitted” this line of the Configuration menu reads
“Extended Azimuth Setup”. (see previous page)
Description The EG-01 resolvers have a 1:2 gear ratio between the input
shaft and the angle data output. This is in order to achieve
higher resolution. However it means that the output moves
through 720

for 360

of input rotation. Thus in Azimuth the
INTRAC seeks to initially resolve this 180

ambiguity.
