OPERATION INTRAC-305
Page 8 INTRAC-305 MANUAL - Issue 3.2 ©2011 Advantech Wireless
Emergency Stop Button Pressing the button removes all drive from the antenna. The
button locks in the safe position when pressed. To enable
drive to return to the antenna the button must be rotated
clockwise until it releases.
On/Off Switch
Illuminated rocker switch to apply power to the INTRAC-305.
Illuminated when the INTRAC is on. On Dual Redundant
PSU units the rocker switch is replaced by status LEDs.
Dual Redundant Status Leds
On Dual Redundant PSU units there is a green and red status
LED for each PSU. Green indicates that the PSU is powered
and working normally. Red indicates thjat the PSU is
powered but faulty. When the PSU is unpowered both LEDs
will be off. The INTRAC will operate correctly when at least 1
green LED is illuminated.
THE MENU STRUCTURE
The diagram above shows the various menus in a “tree”
structure.
The menu headings in heavy type are selected by the six
menu
keys from the “HOME” menu. The headings in the box
below “NEW MODE” are selected by the menu keys in NEW
MODE. The shaded area headings are sub menus of the
MODELS, CONFIGURATION and SYSTEM SETUP menus.
They are accessed by using the “Next Field” menu key from
the appropriate menu followed by the “ENTER” key on the
numeric keypad.
MODELS
RAPID MODEL GENERATE
PROGRAM TRACK
RESERVE MODEL
EDIT IESS-412
EDIT NORAD
EDIT STAR TRACK
EDIT SATELLITE
TABLE
CONFIGURATION
EDIT SATELLITE
TABLE
BEACON FREQUENCY
SYSTEM SETUP
FINE TUNE
STATION COORDINATES
DATE & TIME
AZ& EL BEAMWIDTH
CONTRAST & BRIGHTNESS
STOW SETUP
FITTED OPTIONS
selected by menu list
SOFT LIMITS
EXTENDED AZ not avail
DIAGNOSTICS OFF
BEACON THRESHOLD
DIAGNOSTICS ON
CLEAR MODELS
HOME
NEW MODE FUNCTION ALARMS
MANUAL/ GOTO AUTO CONTINUE AUTO NEW MODEL
STANDBY
STOW
SEARCH GOTO SATELLITE GOTO POSITION
BEACON POL not avail
REMOTE LOCAL
