22 Auto Path VA Device Settings Window
The Auto Path VA Device Settings window has the following items:
• Server Name. The name or IP address of the server.
• Disk Array Unit. The serial number of the array.
• Device Serial Number. The serial number of the selected device.
• Device Name. The name of the selected device.
• Load Balancing Policy. The load balancing policy for the selected device.
• Preferred Path Number. The preferred path for the selected device. Shown only when the selected
device does not have a Load Balancing Policy.
• Path Number. The index number for the path.
• State. The state of the path:
– Active. The device is in use.
– Failed. The device is no longer in use or all paths to the device have failed.
• Controller Port. The controller’s port number for the device.
• Port Path Target LUN. The physical path identifier.
• OK button. Applies the changes, and then displays the Devices window.
• Cancel button. Cancels the changes and returns to the Devices window.
