18 Auto Path VA Devices Window
The Auto Path VA Devices window contains the following items:
• Server Name. Drop-down menu that lets you select a server.
• Disk Array. Drop-down menu that lets you select the active array for the window.
• Devices tab. Opens the Devices window.
• Adapters tab. Opens the Adapters window. See section ”Auto Path VA Adapters Window” on
page 25 for information.
• Device#. The total number of devices (LUNs) configured on the selected array.
• Device Name. The device name.
• Serial#. The device serial number.
• State. The state of each device:
– Active. The device is in use.
– Failed. The device is no longer in use or all paths to the device have failed.
• # of Paths. The number of paths to the device which is a multiple of the controllers and host bus
adapters. For example, there are four paths to the device when using two controllers and two host
bus adapters.
• Load Balance Policy. The load balancing policy currently selected for the device.
• Device Settings button. Opens the Device Settings window. See section ”Auto Path VA Device
Settings Window” on page 21 for information.
