Table 17 SNMP IP Security window (continued)

Description

Item

YYYY:YYYY:YYYY:YYYY:YYYY:YYYY:YYYY:YYYY when Y is a hexadecimal number).
Enter the hexadecimal numbers only, and do not enter the colons. The cursor can be
moved between the entry fields using the Tab key.

Is selected when entering an IPv4 address. The IPv4 address can be entered in the IP address
text box when this button is selected.

IPv4

Is selected when entering an IPv6 address. The IPv6 address can be entered in the IP address
text box when this button is selected.

IPv6

Adds new IP addresses to the IP Address list box.

Set

Allows you to add, delete, or change SNMP trap information. The registered IP address is
the trap destination for the specified community.

Community & Trap

Each community can have more than one defined IP address (see

“Adding a community

name” (page 11)

and

“Adding a community IP address” (page 13)

).

You can register up to 32 community names and up to 32 IP addresses per community
name.

You can use up to 180 alphanumeric characters in a community name. You cannot use
the following special characters: ", \, ;, :, ,, *, ?, <, >, |, /, ^, &, and %.

Allows you to add, delete or change SNMP system group information. If system group
information has already been registered, the registered information displays. To register the

System Group

system group information, the Extension SNMP checkbox must be selected. To register system
group information, click Apply. System group information includes the following items:

Name: This is the name of the connected storage system device. Remote Web Console
users can change the device name. The name can include up to 180 alphanumeric
characters, but cannot include the following special characters: ", \, ;, :, ,, *, ?, <, >,
|

, /, ^, &, and %.

The device name is required to use SNMP Agent. Make sure to document the device
name, because settings will be cleared when the SVP is replaced.

Contact: Contact information such as personnel and telephone numbers where you can
inquire about the connected storage system. Remote Web Console users can change
contact information in the Modify mode. contact information using up to 180 alphanumeric
characters (ASCII codes), except for some symbols, such as ", \, ;, :, ,, *, ?, <, >, |,
/

, ^, &, and %.

A contact name is required to use SNMP Agent. Make sure to document the contact
name, because settings will be cleared when the SVP is replaced.

Location: Location of connected storage system. Remote Web Console users can change
device locations with the modify mode. You must enter a device location using up to 180
alphanumeric characters (ASCII codes). You cannot use some symbols, such as ", \, ;,
:

, ,, *, ?, <, >, |, /, ^, &, and %.

The device location is required to use SNMP Agent. Make sure to document the device
location, because the settings will be cleared when SVP is replaced.

Executes test report of the trap to the community registered in the XP P9000 disk storage
system. You must be in Modify mode to use this button. You must have Storage Administrator
(Initial Configuration) role.

Trap Test

Implements settings made on this window. You must be in Modify mode to use this button.
You must have the Storage Administrator (Initial Configuration) role.

Apply

Cancels settings made on this window.

Cancel

34

SNMP GUI reference
