3 Using the LUSE GUI
This chapter describes the GUI for LUN Expansion (LUSE) operations.
• LUN Expansion (LUSE) Window
• Set LUSE Confirmation Dialog Box
• Concatenation List Dialog Box
• Reset LUSE Confirmation Dialog Box
• Release LUSE Confirmation Dialog Box
• LUSE Detail Dialog Box
LUN Expansion (LUSE) Window
Figure 2 (page 10) depicts the LUN Expansion (LUSE) window. Later sections in this chapter explain
components of the LUSE window. For instructions on how to display this window, see Launching
LUN Expansion (LUSE) .
Figure 2 LUN Expansion (LUSE) Window
LDEV Information Tree
The LDEV Information tree in the upper left corner of the LUN Expansion tab provides an outline
view of the LDKC (logical DKC) and CU numbers installed on the storage system.
LDEV Detail Table
The LDEV Detail table is in the upper right corner of the LUN Expansion tab. The LDEV Detail table
displays detailed information for all open-system LDEVs in the selected CU (refer to
Table 4 (page
11) ).
