HP Tower Uninterruptible Power System - Manual (Page 62)

Specifications 62
UPS model Load segment Output receptacles
— — 1 x L6-20R
— 2 3 x IEC-320-C13
— — 1 x IEC-320-C19
R/T3000 INTL 1 3 x IEC-320-C13
— — 1 x IEC-320-C19
— 2 3 x IEC-320-C13
— — 1 x IEC-320-C19
Power protection specifications
UPS model VA Nominal power
rating (W) Nominal voltage setting
R/T3000 NA/JPN 2880 /
2400
2700 / 2250 120/100
R/T3000h
NA/JPN 3300 3000 204
R/T3000 INTL 3300 3000 230
Output tolerance specifications
Source of power Regulation
Utility power (nominal
range) -10% to +6% of nominal output voltage rating
(within the guidelines of the Computer Business
Equipment Manufacturers Association)
Battery power ±5% of nominal output voltage rating
Output feature specifications
Feature Specification
Online efficiency 94% nominal input voltage
Voltage wave shape Sine wave; 5% THD with typical PFC load
Surge suppression 300J via MOVs
Noise filtering EN 55022 line filter for normal and common mode
use
Battery specifications
Feature Specification
Type 12 V, 5 AH, sealed, maintenance-free, rechargeable, valve
regulated lead-acid batteries with a 3-5 year service life at 25°C
(77°F).
Voltage The battery modules have a battery string voltage of 120 V.
