Specifications 61
Specifications
UPS physical specifications
Parameter Value
Height 8.9 cm (3.5 in)
Depth 63.5 cm (25 in)
Width 44.5 cm (17.5 in)
Weight 37 kg (82 lb)
ERM physical specifications
Parameter Value
Height 8.9 cm (3.5 in)
Depth 63.5 cm (25 in)
Width 44.5 cm (17.5 in)
Weight 45 kg (100 lb)
UPS input specifications
UPS model Utility voltage
frequency (Hz) Available settings utility
voltage (VAC) Branch circuit
rating (A) Line cord
R/T3000
NA/JPN 50/60 100, 110, 120, 127 30 Nondetachable power
cord with NEMA L5-30
plug
R/T3000h
NA/JPN
50/60 200/208 1 , 220, 230,
240
20 Nondetachable power
cord with NEMA L6-20
plug
R/T3000 INTL 50/60
200/208, 220, 230,
240
16 Detachable power cord
with country-specific plug
1 The output voltage is 204 for this setting.
UPS output specifications
UPS model Load segment Output receptacles
R/T3000 NA/JPN
1 2 x 5-20R T-Slot
— — 1 x L5-30R
— 2 2 x 5-20R T-Slot
R/T3000h NA/JPN 1 3 x IEC-320-C13
— — 1 x IEC-320-C19
