Manual Migration Plans navigation tree
The Manual Migration Plans navigation tree lists the parity groups, external volume groups, and
Thin Provisioning virtual volume groups contained in the storage system.
Description Type Item
This icon indicates a fixed parity group when it appears in the Parity Group folder.
A fixed parity group cannot be a part of an Auto Migration plan. However, a icon
volume in a fixed parity group can be used as a source or target volume in a
Manual Migration plan.
RAID1 parity group in HDD class A. A similar HDD class A icon indicating RAID5
or RAID6 might also appear. icon
RAID1 parity group in HDD class B. A similar HDD class B icon indicating RAID5
or RAID6 might also appear. icon
RAID1 parity group in HDD class C. A similar HDD class C icon indicating RAID5
or RAID6 might also appear. icon
RAID1 parity group in HDD class D. A similar HDD class D icon indicating RAID5
or RAID6 might also appear. icon
The parity group ID, usage rates, and corresponding CLPR appear directly to the
right of the parity group icon in the following convention: field Parity group identifier
1-3(1-4)(!12/13%, 01:CLPR1)
Each element of the preceding example is described below.
•
1-3: indicates the parity group ID.
• (1-4): indicates a parity group to which parity group 1-3 is connected.
•
!12/13%: indicates the average usage rate/maximum usage rate for the parity
group. An exclamation mark (!) indicates that the reported usage rate is likely
to be inaccurate. “+0” succeeding either of the usage rates indicates that the
usage rate is between 0 and 1 percent.
•
01:CLPR1: indicates the number and name of the CLPR corresponding to the
parity group.
The external volume group ID and corresponding CLPR appear directly to the right
of the external volume group icon in the following convention: field External volume group
identifier
E1-2(03:CLPR3)
Each element of the preceding example is described below.
•
E1-2: indicates the external volume group ID.
• 03:CLPR3: indicates the number and name of the CLPR corresponding to the
external volume group.
NOTE: No volumes in an external volume group can be selected as target
volumes.
The Thin Provisioning group ID and corresponding CLPR appear directly to the
right of the Thin Provisioning group icon in the following convention: field Thin Provisioning
group identifier
(X16-1,03:CLPR3)
•
X16-1: indicates the Thin Provisioning virtual volume group ID.
• 03:CLPR3: indicates the number and name of the CLPR corresponding to the
Thin Provisioning virtual volume group.
Manual Migration window 49
