Figure 7 3DC multi-target configuration
Table 5 Pair status when P-VOL of Continuous Access Journal Z delta resync pair is as a source
volume
Status Pair Name
SUSPEND or DUPLEX Continuous Access Synchronous Z pair
Any pair status can be acceptable Continuous Access Journal Z pair
Hold or Hlde Continuous Access Journal Z pair for delta resync operation
Table 6 Pair status when S-VOL of Continuous Access Journal Z delta resync pair is a source volume
Status Pair Name
Any pair status can be acceptable Continuous Access Synchronous Z pair
SUSPEND Continuous Access Journal Z pair
Hold or Hlde Continuous Access Journal Z pair for delta resync operation
Also, the source and target volumes must belong to the same CLPR.
Auto LUN and Continuous Access Journal
You cannot select a volume in COPY or PAIR status as a source volume.
If you create a Continuous Access Journal pair for a delta resync operation in a 3DC multi-target
configuration, the primary volume or the secondary volume of the delta resync pair can be used
as a source volume. To use the primary or secondary volume as a source volume, you must ensure
that the status of each pair in the 3 DC multi-target configuration is as shown in
Table 7 (page 16)
and Table 8 (page 16) .
Also, the source and target volumes must belong to the same CLPR.
Auto LUN and Continuous Access Journal 15
