Specifications 47
1 The output voltage is 204 for this setting.
UPS output specifications
UPS model Load segment Output receptacles
R3000 NA 1 2 x 5-15R
1 x L5-30R
2 2 x 5-15R
3 2 x 5-15R
R3000j JPN 1 2 x 5-15R
1 x L5-30R
2 2 x 5-15R
3 2 x 5-15R
R3000h NA/JPN 1 3 x IEC-320-C13
1 x L6-20R
2 3 x IEC-320-C13
3 3 x IEC-320-C13
R3000 INTL 1 3 x IEC-320-C13
1 x IEC-320-C20
2 3 x IEC-320-C13
3 3 x IEC-320-C13
Power protection specifications
UPS model VA Nominal power rating
(W) Nominal voltage
setting
R3000 NA 2880 2700 100, 110, 120, 127
R3000j JPN 2400 2250 100, 110, 120, 127
R3000h NA/JPN 3000 2700 200, 220, 230, 240
R3000 INTL 3000 2700 200/208, 220, 230,
240
Voltage specifications
Configuration setting (VAC) Available nominal output voltage (VAC)
100 100
110 110
120 120
127 127
200 200
