toptools user guide
Click on the Maps button in the Device Selector and select the option View Maps to display the Maps page. The
Maps page lists maps that have been created based on the networks that have been discovered by Toptools. The
following information is provided for each map:
Name Name of the map.
Type Either a ‘Network’ or ‘Segment’ map.
Create Date The date the map was created.
View The style of the map. For example, ‘hierarchical’.
Owner System (default maps created) or the User Id of the person who created the map.
Maps appear in the list only after topology is complete. If you want the map to display in a separate browser
window, check the Map in Separate Window box. When you double-click on a map in the list, a new browser
window opens displaying the map.
Click the Full Network button to generate a map of the entire network.
Select the Delete button to remove a map from the list and the map file on the server. It may take a minute for the
map list to refresh and reflect the deletion.
79
