Hardware options installation 41
16. Align and install the heatsink. Alternate tightening the screws until the heatsink is seated properly.
17. Repeat these steps for the second processor and heatsink.
18. Install the front bezel/hard drive cable assembly.
19. Connect the SAS/SATA cable, SGPIO cable, and hard drive power cable to the hard drive
backplane.
20. Install the access panel (on page 16 ).
21. Install the hard drives (" Hot-plug SAS or SATA hard drive option " on page 31 ).
22. Install the server blade (" Installing a server blade " on page 26 ).
23. Power up the server blade (on page 14 ).
HP Trusted Platform Module option
Use these instructions to install and enable a TPM on a supported server blade. This procedure includes
three sections:
1. Installing the Trusted Platform Module board.
2. Retaining the recovery key/password (on page 43 ).
3. Enabling the Trusted Platform Module (on page 44 ).
Enabling the TPM requires accessing the ROM-Based Setup Utility (RBSU) (" HP ROM-Based Setup
Utility " on page 56 ). For more information about RBSU, see the HP website
( http://www.hp.com/support/smartstart/documentation ).
TPM installation requires the use of drive encryption technology, such as the Microsoft® Windows®
BitLocker™ Drive Encryption feature. For more information on BitLocker™, see the Microsoft website
(
http://www.microsoft.com ).
CAUTION: Always observe the guidelines in this document. Failure to follow these guidelines
can cause hardware damage or halt data access.
When installing or replacing a TPM, observe the following guidelines:
