Component identification 10

The symbols correspond to the symbols located on the interconnect bays. For more information, see the
HP ProLiant BL685c G7 Server Blade Installation Instructions that ship with the server blade.

DIMM slot identification

Each processor supports eight DIMM slots:

•

Processor 1 and processor 4 DIMM slots

•

Processor 2 and processor 3 DIMM slots

For installation guidelines and population order, see "Memory option (on page

)."

Mezzanine connector definitions

Item

Connector

Card support

Mezzanine connector 1

PCIe x8

Type I mezzanine card only
