# ls /dev/rdsk/c4t0d* | ./inqraid −CLI −fp
DEVICE_FILE PORT SERIAL LDEV CTG H/M/12 SSID R:Group PRODUCT_ID
c4t0d0* CL1-E 15005 00 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d1* CL1-E 15005 01 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d2* CL1-E 15005 02 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d3* CL1-E 15005 03 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d4* CL1-E 15005 04 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d5* CL1-E 15005 05 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d6* CL1-E 15005 06 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d7* CL1-E 15005 07 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d8* CL1-E 15005 08 - s/s/ss 0004 5:01-03 OPEN-V
c4t0d9 CL1-E 15005 09 - s/s/ss 0004 5:01-03 OPEN-V
Figure 9 Displaying Database Validator Volumes for Sample Configuration
Displaying Database Validator Volumes using raidvchkdsp
The raidvchkdsp command (see
) displays the relation between the Device_File and the
paired volumes based on the group (as defined in the local instance configuration definition file). If
the Device_File column shows Unknown to HOST (instance), then the volume is not recognized on its
own HOST and the raidvchkdsp command will be rejected in protection mode. The non-permitted
volume is shown without LDEV# information (LDEV# is -).
•
See the HP StorageWorks XP RAID Manager User's Guide for more examples of the raidvchkdsp
command and parameter definition and displayed field definitions.
raidvchkdsp -g vg01
-fd -v cflag
Example of -fd option showing Unknown vol.
Group PairVol Device_File Seq# LDEV# BR-W-E-E MR-W-B BR-W-B SR-W-B-S
vg01 oradb1 Unknown 2332 - - - - - - - - - - - - - - -
vg01 oradb2 c4t0d3 2332 3 D E B R D D D D E E D E D D
raidvchkdsp -g vg01 -fd
-v cflag
Example of -v cflag option.
Group PairVol Device_File Seq# LDEV# BR-W-E-E MR-W-B BR-W-B SR-W-B-S
vg01 oradb1 c4t0d2 2332 2 D E B R D D D D E E D E D D
vg01 oradb2 c4t0d3 2332 3 D E B R D D D D E E D E D D
Figure 10 Examples Showing -Fd and -Vcflag Options for the Raid Vchkdsp Command
Displaying Database Validator Volume using raidvchkscan
The raidvchkscan command (see
) displays the fibre port of the storage system, GID (host
group number), LDEV mapped for LUN#, and the parameters for validation checking regardless of
the configuration definition file.
•
See the HP StorageWorks XP RAID Manager User's Guide for more examples of the raidvchkscan
command, parameter definition, and displayed field definitions.
