Displaying database validator volumes – HP XP Array Manager Software User Manual
Page 24

# raidvchkset -g oradata -d data -vt data9 -vs 4 2880 71184960
# raidvchkset -g oralog -d log1 -vt redo9 -vs 1 2880 4799520
Note: 2879 + 1 = 2880
The SLBA and the ELBA is the offset from "vxdisk list" command.
Example for the redo log
# fire-2 >
vxdisk list c4t0d9s2
Device: c4t0d9s2
devicetag: c4t0d9
type: sliced
hostid: fire-2
disk: name=dg901_1 id=1031839952.2594.fire-2
group: name=dg901 id=1031840145.2607.fire-2
info: privoffset=1
flags: online ready private autoconfig autoimport imported
pubpaths: block=/dev/vx/dmp/c4t0d9s2 char=/dev/vx/rdmp/c4t0d9s2
privpaths: block=/dev/vx/dmp/c4t0d9s1 char=/dev/vx/rdmp/c4t0d9s1
version: 2.2
iosize: min=512 (bytes) max=256 (blocks)
public: slice=4 offset=0 len=
4799520 private: slice=3 offset=1 len=2879
update: time=1031840146 seqno=0.5
headers: 0 248
configs: count=1 len=2104
logs: count=1 len=318
Defined regions:
config priv 000017-000247[000231]: copy=01 offset=000000 enabled
config priv 000249-002121[001873]: copy=01 offset=000231 enabled
log priv 002122-002439[000318]: copy=01 offset=000000 enabled
Multipathing information:
numpaths: 1
c4t0d9s2 state=enabled
Figure 8 Example of Enabling Database Validator Checking with the LVM Consideration
Displaying Database Validator Volumes
The Database Validator volumes can be displayed using the following XP RAID Manager commands:
•
inqraid
•
raidvchkdsp
•
raidvchkscan
Displaying Database Validator Volumes Using inqraid
To verify the validation volumes, you can use the inqraid −fp command with the −CLI option (see
). Database Validator checking is enabled for the volumes with an asterisk (*). For further
information on the inqraid command, see the HP StorageWorks XP RAID Manager User's Guide.
Performing Database Validator Operations
24
