Controls and Indicators
SL500 (M852x) Tape Library Installation and User’s Guide—541531-010
2 -3
Keypad
Table 2-1. Keypad Buttons and Indicators
Buttons/Indicators Description
Service Robot
Indicator
LED is lit when the robot is not functioning. Replace
the robotics unit.
Library Active
Indicator
!
LED is normally solid green.
!
LED turns off when the tape library experiences
a failure. If it never turns on, an initialization or
power failure has occurred.
Service Required
Indicator
!
LED is normally solid green.
!
LED is lit when the tape library experiences a
non-robotic failure.
Open Door
Indicator
!
LED flashes amber when the Open Door button
is pressed.
!
LED is solid amber when the robot is parked in
the robotics unit.
!
LED flashes during initialization and audit.
!
LED is not lit when the library is ready for
customer use.
Button
When pressed:
1. Software allows the current job to complete. This
could take awhile.
2. Software retracts the robot into the robotics unit
so that it will not be damaged when you open
the door with the key.
Open CAP
Indicator
!
LED is amber when any CAP doors are open
!
LED is not lit when all CAP doors are shut
!
LED flashes during audit
Button
Button is used to tell the robot to open the CAP
doors.
