DTV mode

Resolution

Component

HDMI/DisplayPort (DTV)

480i

o

x

576i

o

x

480p

o

o

576p

o

o

720p

o

o

1080i

o

o

1080p

o

o

NOTE:

HDMI/DisplayPort input mode may identified in PC resolution: 640 x 480 / 60 Hz, 1280 x 720 / 60 Hz,

1920 x 1080 / 60 Hz or DTV resolutions: 480p, 720p, 1080p.

NOTE:

Vertical frequency: To enable the user to watch the product display, screen image should be

changed tens of times every second like a fluorescent lamp. The vertical frequency or refresh rate is the
times of image display per second. The unit is Hz.

Horizontal frequency: The horizontal interval is the time to display one vertical line. When 1 is divided by the
horizontal interval, the number of horizontal lines displayed every second can be tabulated as the horizontal
frequency. The unit is kHz.

IR codes

All models do not support the HDMI/USB function.

Some key codes are not supported depending on the model.

Code (Hexa)

Function

Note

95

Energy Saving

R/C BUTTON

08

POWER

R/C BUTTON (ON/OFF)

0B

INPUT

R/C BUTTON

C4

Display On

R/C BUTTON

C5

Display Off

R/C BUTTON

43

MENU

R/C BUTTON

40

UP (

∧)

R/C BUTTON

41

Down (

∨)

R/C BUTTON

07

Left (<)

R/C BUTTON

06

Right (>)

R/C BUTTON

44

OK

R/C BUTTON

28

BACK

R/C BUTTON

70

Chapter 10 Specifications
