7

Making connections

Connect various external devices to the ports on the display back panel.

1.

Find an external device you want to connect to your display shown on the following illustration.

2.

Check the connection type of the external device.

3.

Go to the appropriate illustration and check the connection details.

Item

Source

Reference

Item

Source

Reference

(1)

Computer

HDMI connection on page 42

DisplayPort connection on page 41

Connecting to the LAN on page 44

(4)

HD
receiver

HDMI connection on page 42

DisplayPort connection on page 41

Component connection on page 43

(2)

USB

Connecting to a USB on page 44

(5)

DVD

HDMI connection on page 42

DisplayPort connection on page 41

Component connection on page 43

(3)

Speakers

Component connection on page 43

(6)

VCR

Component connection on page 43

NOTE:

For sound, you must connect an optional speaker.
