Specifications, Inch models, 10 specifications – HP LD4235 41.92-inch LED Digital Signage Display User Manual
Page 73

10 Specifications
42-inch models
LCD Panel
Screen type
1064.67 mm Wide (42 inch) TFT (Thin Film Transistor) LCD (Liquid
Crystal Display) Panel.
Visible diagonal size : 1064.67 mm
Pixel pitch
0.4833 mm (H) x 0.4833 mm (V)
Video Signal
Max resolution
RGB : 1920 x 1080 @ 60 Hz
HDMI/ DisplayPort : 1920 x 1080 @ 60 Hz
It may not be supported depending on the OS or video card type.
Recommended resolution
RGB : 1920 x 1080 @ 60 Hz
HDMI/ DisplayPort : 1920 x 1080 @ 60 Hz
It may not be supported depending on the OS or video card type.
Horizontal frequency
30 kHz to 83 kHz
Vertical frequency
50 Hz to 60 Hz
Synchronization type
Separate Sync, Composite Sync, Digital
Input connector
15-pin D-Sub type, HDMI (digital), Component, RS-232C, LAN,
DisplayPort, USB
Power
Rated voltage
AC 100-240 V~ 50/60 Hz 1.3 A
Power consumption
On Mode : 90 W Typ
Sleep Mode (if WOL is off) : ≤ 0.5 W
Sleep Mode (if WOL is on) : ≤ 2.0 W
Off Mode : ≤ 0.5 W
Environmental
conditions
Operating Temperature
Operating Humidity
0°C to 40°C
10% to 80%
Storage Temperature
Storage Humidity
-20°C to 60°C
5% to 95%
Dimensions
W x H x D, weight)
(no stand or speakers)
962.2 mm x 560.8 mm x 77 mm
37.88 in x 22.08 in x 3.03 in
12.8 kg
28.22 lbs
(stand, no speakers)
962.2 mm x 636.5 mm x 297.7 mm
37.88 in x 25.06 in x 11.72 in
14.1 kg
31.09 lbs
42-inch models
63
