24 LUN Manager for the XP10000/XP12000
9. Click OK. The settings are applied to the disk array.
The next step is to register hosts to the appropriate host group.
CAUTION: Do not select options other than those listed in Table 9 .
Registering hosts in host groups
Before you can set LU paths, you must register hosts in host groups. For example, if HP-UX and Windows
hosts are connected to a port, you must register them separately in two different host groups.
When registering a host, you can assign a nickname to the host bus adapter. If you assign a nickname,
you will be able to easily identify each host bus adapter in the LUN Manager main pane. Although
WWNs are also used to identify each host bus adapter, a nickname is more helpful because you can
name host bus adapters after the host installation site or the host owners.
When using nicknames, note the following:
• A nickname can consist of up to 32 ASCII characters (letters, numerals, and symbols). You cannot use
the following characters for nicknames:
\ / : , ; * ? " < > | ~
• You cannot use the space character for the first or the last nickname character.
• Nicknames are case sensitive. For example, hp and HP are different nicknames.
To register hosts in a host group:
1. Start LUN Manager, and display the LUN Manager pane ( Figure 7 ).
Table 9 Host mode options
No. Host Mode option When to select option
2 VERITAS Database
Edition/Advanced
Cluster
When VERITAS Database Edition/Advanced Cluster for Real Application Clusters
or VERITAS Cluster Server 4.0 (I/O fencing function) is used
6 TPRLO When all the following conditions are satisfied:
• The host mode 0C Windows or 2C Windows Extension is used
• The Emulex host bus adapter is used
• The mini-port driver is used
• TPRLO=2 is specified for the mini-port driver parameter of the host bus adapter
7 Automatic
recognition function
of LUN
When all the following conditions are satisfied:
• The host mode 00 Standard or 09 Solaris is used
• SUN StorEdge SAN Foundation Software Version 4.2 or later is used
• You want to automate recognition of increase and decrease of devices when a
genuine SUN HBA is connected
12 Undisplay function of
ghost LUN
When all the following conditions are satisfied:
• The host mode 08 HP is used
• You want to suppress creation of device files for devices to which the paths are
not defined
13 SIM report at link
failure
When the user wants to be informed by SIM (service information message) that the
number of link failures detected between ports exceeds the threshold.
14 HP TruCluster with
TrueCopy function
When all the following conditions are satisfied:
• The host mode 07 Tru64 is used
• You want to use TruCluster to set a cluster to the Continuous Access XP P-VOL
and S-VOL, respectively
