Page 13

Component
Identification
13
Item Description
6
Processor 2 memory bank 1 (shown populated)
7 DIMMs
5-8
8
Processor socket 2 (shown populated)
9
SCSI Backplane board connector 2
10 Fan
connectors
11
Power button/LED board connector
12
SCSI Backplane board connector 1
13
Processor socket 1 (shown populated)
14 DIMMs
1-4
15
Processor 1 memory bank 1(shown populated)
16
Processor 1 memory bank 2
17
Smart Array 6i Battery-Backed Write Cache Enabler
(optional)
18
Smart Array 6i controller
19
Power converter modules
20
Fibre Channel Adapter (optional)
System Maintenance Switch
Position Function
Default
1*
iLO Security override
Off
2 Configuration
lock Off
3 Reserved
Off
4 Reserved
Off
5* Password
disabled Off
6* Reset
configuration Off
7 Reserved
Off
8 Reserved
Off
