1
On all enclosures, the second volume is created for the use of the 2 TB hard drive model.
2
On all enclosures, the third volume is created for the use of the 3 TB hard drive model.
Table 14 LFF ENT-SAS drive configuration (450 GB, 600 GB)
LUN ID Volume name
prefix Assigned
CTLR Disk slots Encl ID Vdisk name prefix Vdisk or
spare Kit type
n/a n/a 1 1 n/a Spare Starter
1 A 2-6 1 HPIBX_ Vdisk Starter
2 B 7-12 1 HPIBX_ Vdisk Starter
3 A 1-6 2 HPIBX_ Vdisk Starter
4 B 7-12 2 HPIBX_ Vdisk Starter
n/a n/a 1 3 n/a Spare Expansion#1
5 A 2-6 3 HPIBX_ Vdisk Expansion#1
6 B 7-12 3 HPIBX_ Vdisk Expansion#1
7 A 1-6 4 HPIBX_ Vdisk Expansion#1
8 B 7-12 4 HPIBX_ Vdisk Expansion#1
n/a n/a 1 5 n/a Spare Expansion#2
9 A 2-6 5 HPIBX_ Vdisk Expansion#2
10 B 7-12 5 HPIBX_ Vdisk Expansion#2
11 A 1-6 6 HPIBX_ Vdisk Expansion#2
12 B 7-12 6 HPIBX_ Vdisk Expansion#2
Table 15 SFF ENT-SAS drive configuration (300 GB, 900 GB)
LUN ID Volume name
prefix Assigned
CTLR Disk
slots Encl Id Vdisk name prefix Vdisk or
spare Kit type
n/a n/a 1 1 n/a Spare Starter
1 A 2-6 1 HPIBX_ Vdisk Starter
2 B 7-12 1 HPIBX_ Vdisk Starter
3 A 13-18 1 HPIBX_ Vdisk Starter
4 B 19-24 1 HPIBX_ Vdisk Starter
n/a n/a 1 2 n/a Spare Expansion#1
5 A 2-7 2 HPIBX_ Vdisk Expansion#1
6 B 8-13 2 HPIBX_ Vdisk Expansion#1
7 A 14-19 2 HPIBX_ Vdisk Expansion#1
8 B 20-25 2 HPIBX_ Vdisk Expansion#1
n/a n/a 1 3 n/a Spare Expansion#2
9 A 2-7 3 HPIBX_ Vdisk Expansion#2
10 B 8-13 3 HPIBX_ Vdisk Expansion#2
11 A 14-19 3 HPIBX_ Vdisk Expansion#2
12 B 20-25 3 HPIBX_ Vdisk Expansion#2
24 StoreAll 9320 storage provisioning
