Figure 3 Performance storage profile
Volume configuration
A volume is a logical partition of a pool and is exposed as block devices for operating system
access. Each volume can also be perceived as a storage representation of a segment. Since the
StoreAll file system imposes a limit of 8 TB for each segment, the volume sizes are also ensured to
be within this supported limit.
Volume configurations are dependent on drive type. Table 6 (page 11) and Table 7 (page 11)
show the drive type for each storage layout with the MDS600 enclosure.
Table 6 Volume configuration for 2 TB drives
Performance Maximum capacity Balanced capacity 2 TB Drives
22 14 16 Number of volumes
22 x 4 TB 6 x 8 TB + 8 x 7 TB 12 x 6 TB + 4 x 7 TB Volume size
Table 7 Volume configuration for 3 TB drives
Performance Maximum capacity Balanced capacity 3 TB Drives
33 21 24 Number of volumes
33 x 4 TB 9 x 8 TB + 12 x 7 TB 18 x 6 TB + 6 x 7 TB Volume size
