Table C–2: Parallel Interface Pin Assignments
Pin
Signal
Direction
1
DataStrobe
In
2
Data 1
In
3
Data 2
In
4
Data 3
In
5
Data 4
In
6
Data 5
In
7
Data 6
In
8
Data 7
In
9
Data 8
In
10
ACK
Out
11
Busy
Out
12
Call (PE)
Out
13
Select
Out
14–15
Not Connected
–
16
0 Volts (Logic Ground)
–
17
Chassis Ground
–
18
5 Volts
Out
19–29
Ground
–
30
InputP rimeRet
Out
31
InputP rime
In
32
F ault
Out
33
Aux Out 1
1
–
34
Not Connected
–
35
Aux Out 2
1
–
36
Not Connected
–
1
Ignored
