Component identification 15
Item Description
12 Second drive cage, box 1 power connector
13 Fan connector 1
14
Discovery services connector
15 Front video connector
16 USB connector
17 Power supply backplane connector
18
SATA optical drive connector
19 NMI jumper
20 System battery
21 SD card slot
22
Secondary (processor 2) PCI riser connector
23 System maintenance switch
24 Processor 2 socket
25 TPM connector
26 Primary (processor 1) PCI riser connector
27 FlexLOM
28 SAS connector 1
29 SAS connector 2
30
Cache module connector
31 Processor 1 socket
32 RDX power connector
System maintenance switch
Position Default Function
S1 Off Off = HP iLO security is enabled.
On = HP iLO security is disabled.
S2 Off Off = System configuration can be
changed.
On = System configuration is locked.
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password is enabled.
On = Power-on password is disabled.
S6 Off Off = No function
On = ROM reads system configuration
as invalid.
S7 — Reserved
S8 — Reserved
S9
— Reserved
S10 — Reserved
S11 — Reserved
S12 — Reserved
To access redundant ROM, set S1, S5, and S6 to on.
