5. Output data 1~N
It symbolized codes of output ports; the range is from 0x00 to the maximum number that the device
supports.
6. Input data 1~N
It symbolized codes of input ports; the range is from 0x00 to the maximum input number that the
device supports. 00x0 means input No.1; 0x01 means input No.2. Please caution that the maximum
input port number’s code plus ONE symbolized closing this port. For example, the device supports
eight input ports, then 0x07 symbolizes No.8 port, 0x08 symbolizes close.
7. Pre-select input through long-distance control
Similar with input by keyboard
8. Address
0x90
9. Response
a. The equipment correctly receives and executes the command. Then execute the command and
response as follows. 0xeb，Address，Command，0x01，0xfa，Redundancy.
b. The equipment receives the address correctly but data out of the range. Then doesn’t execute
the command and response as follows. 0xeb ， Address ， Command ， 0x01 ， 0xf2 ，
Redundancy.
c. The equipment receives correctly but is controlled through keyboard. Then doesn’t execute the
command and response as follows. 0xeb，Address，Command，0x01，0xf3，Redundancy.
d. The equipment receives the address correctly but data length wrongly. Then doesn’t execute
the command and response as follows. 0xeb ， Address ， Command ， 0x01 ， 0xf7 ，
Redundancy.
e. The equipment receives the address correctly but the command is no support. Then doesn’t
execute the command and response as follows. 0xeb，Address，Command，0x01，0xf1，
Redundancy.
f. The equipment receives the address wrongly. No response.
3.1.6 Commands
1. Command 0x00(two functions)
Function 1 Get the equipment address and software version
Format 0xeb, 0x00, 0x00, 0x01, 0x01
Response 0xeb, Address, 0x00, 0x02, Version, 0xfa, Redundancy
For example：Get the equipment address and software version
Commands: 0xeb, 0x00, 0x00, 0x01, 0x01
Response: 0xeb, 0x90, 0x00, 0x02, 0x10, 0xfa, Redundancy
Function 2 Get the information of the equipment’s type
Format 0xeb, 0x90, 0x00, 0x01, 0x49
Response
0xeb, 0x90, 0x00, 0x03, Input Signal Type，Maximal Input
Channel Quantity，Maximal Output Channel Quantity
Note: The value of Input Signal Type is 0x80,it means DVI type
