b. According to the DOS direction, input the command: telnet 192.168.0.104 9999
(192.168.0.104 9999 is the current device’s IP address) then the information shows as
follows. The serial code of produce: XXXXXXX
MAC address: XX：XX：XX：XX：XX：XX
Vision number of Software: XX.X (XXXXXX)
Press “Enter” to come into the mode of setting parameter.
c. Press “Enter” button on keyboard to show the info as below
Change setting: 0 server setting;
1 serial interface setting;
6 safety setting;
7 resume default setting;
8 quit without save;
9 quit and save
Choose step: ??
d. Press 0 and then “Enter”. Information as follows: IP address: <192>
e. Input IP address and then “Enter”. Information as follows:
IP address of setting net gateway:
f. Press “Enter” and then showing as follows:
The masking of subnet: digit of the inputted masking<0=default>
g. Press “enter” and then showing as follows:
Change the passport of telnet (N)
h. Press “enter” then showing as follows:
Change set:
0 server setting;
1 serial interface setting;
6 safety setting;
7 resume default setting;
8 quit without save;
9 quit and save
Choose step: ?
i. Input 9 and press “Enter” to save and quit the operation.
j. Input the command: ping 192.168.0.104, if the above operation is successful, information is
showed as follows:
k. Pinging 192.168.0.104 with 32 bytes of data:
Reply from 192.168.0.104: bytes=32 time<10ms TTL=64
Reply from 192.168.0.104: bytes=32 time<10ms TTL=64
Reply from 192.168.0.104: bytes=32 time<10ms TTL=64
Reply from 192.168.0.104: bytes=32 time<10ms TTL=64
Ping statistics for 192.168.0.104:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss), Approximate round trip times in
milli-seconds: Minimum = 0ms, Maximum = 0ms, Average = 0ms
3. Set a new parameter of IP address according to device’s MAC address:
a. Record the Mac address at rear keyboard.
