Configuring ADSL Service
20 Megabit Modem 310F and 320F User Manual
C
ONFIGURING
ADSL S
ERVICE
This section describes how to configure ADSL data transmission parameters.
1 From the Main Menu ( page 11 ) , type to display the ADSL Menu .
2 From the ADSL Menu , type to display the ADSL Configuration Menu .
You configure ADSL transceiver service from the Megabit Modem 310F
(ATU-C) only. The
ADSL Configuration Menu items are read-only from the
Megabit Modem 320F (ATU-R). You must reset the ADSL Link to activate ADSL
configuration changes (
page 26 ).
2
07/20/99 PAIRGAIN TECHNOLOGIES 03:25:24
ATU-C ADSL MEGABIT MODEM TERMINAL v 1.0
ADSL MENU
1. ADSL PERFORMANCE STATUS
2. 24 HOUR ADSL PERFORMANCE HISTORY
3. 7 DAY ADSL PERFORMANCE HISTORY
4. ADSL ALARM HISTORY
5. ADSL CONFIGURATION MENU
6. ADSL LINK RESET
(M)ain
ENTER CHOICE-->
5
07/20/99 PAIRGAIN TECHNOLOGIES 00:26:09
ATU-C ADSL MEGABIT MODEM TERMINAL v 1.0
ADSL CONFIGURATION MENU
1. STARTUP OPTION ADAPTIVE RATE
2. (MAX) UP DATA RATE 928 ( 64 - 928 Kbps)
3. (MAX) DOWN DATA RATE 7040 ( 64 - 7040 Kbps)
4. (MIN) UP DATA RATE 64 ( 64 - 928 Kbps)
5. (MIN) DOWN DATA RATE 64 ( 64 - 7040 Kbps)
6. STARTUP SNR MARGIN 4dB
7. MARGIN THRESHOLD 3
8. ES THRESHOLD 100
9. ALARM CONFIGURATION LOF=E MAR=E ES=E SES=E LOS=E SELF=E
A. UP INTERLEAVE OPTION 4 msec
B. DOWN INTERLEAVE OPTION 4 msec
(U)ndo (R)eturn (M)ain
ENTER CHOICE-->
