Monitoring Ethernet Bridge Statistics
40 Megabit Modem 310F and 320F User Manual
The following table describes the data displayed on the Bridge Statistics Menu .
Field Definition
Rx Bytes The number of bytes received.
Rx Frames The number of frames received.
Rx MCASTS The number of multicast frames received.
Rx Errors The number of errored frames received.
Rx Runts The number of frames received that are smaller than the Ethernet
minimum of 64 bytes.
Rx MTU Ex The number of frames received that exceed the Maximum Transmit Unit
size of 1518 bytes.
Tx Bytes The number of bytes transmitted.
Tx Frames The number of frames transmitted.
Tx MCASTS The number of multicast frames transmitted.
Tx Ex Cols The number of excessive collision events that have occurred - frame
dropped because of 16 consecutive collisions.
TX Discards The number of frames dropped due to a buffer overflow.
Entries Learned The number of entries learned on the LAN port and added to the bridging
table.
Entries Not Learned The number of entries in the bridging table that were not learned because
the table was full.
LAN Filtered Frames The number of frames filtered on the LAN port by the bridging process.
