Chapter 4: Configuring the Modems
Megabit Modem 310F and 320F User Manual
29
The following table describes the data displayed on the
Source Address Database Menu
.
2
To view all valid Bridge Address Table entries by MAC address:
a
Type
to
select
Read All Valid MAC Entries
.
The message displays:
Searching Database
Eight entries, that result from the search, display. The bucket number indicates the
last bucket searched.
The message displays:
Press C to Continue Searching
b
Type
to display the next eight entries of the search.
When no more entries are found in the database, the message displays:
Search Finished
3
To view a Bridge Address Table entry by MAC address:
a
Type
to
select
Read Entry by MAC Address
.
The message displays:
Please enter MAC Address
(aa:bb:cc:dd:ee:ff)
b
Type the MAC address, then press
.
4
To view all the entries in a specific bucket:
a
Type
to
select
Read Bucket
.
The message displays:
Please enter bucket number
b
Type the desired bucket number, then press
.
Column
Description
TYPE
Indicates the method by which the entry was added to the table.
The options are:
DYN
Dynamic is automatically learned by the LAN port.
STAT
Static is entered manually.
---
Indicates that the table row is empty.
VALID
VAL - Indicates that the entry is valid and being used.
INV - Indicates that the entry is not being used.
MAC ADDRESS
The MAC address associated with the parameters contained in that
row of the bridging table.
1
C
2
ENTER
3
ENTER
