Ethernet Frame Rates
44
Megabit Modem 310F and 320F User Manual
E
THERNET
F
RAME
R
ATES
The following sections show Ethernet maximum frame transmission rates, dependent on the
additional bit and bit stuffing set for the xDSL transmission.
Minimum xDSL Bit Stuffing, One Additional Bit
The values in the table below show the frames per second for the maximum xDSL rate.
Ethernet
Data rate
10 Mbps
Preamble
8 bytes
CRC
4 bytes
Interframe gap
9.60E-06 s
xDSL
Flags
1 byte
FCS
2 bytes
Protocol
2 bytes
Overhead/Frame
5 bytes
Additional bits
1 bit
Bit stuffing
min (min/max)
Frame Size
(da:sa:lt:data:crc
)
[bytes]
xDSL Data Rate
7040
kbps
6400
kbps
3200
kbps
1536
kbps
896 kbps
768 kbps
384 kbps
64 kbps
64
13,512.5
12,284.1
6,142.0
2,948.2
1,719.8
1,474.1
737.0
122.8
128
6,815.1
6,195.5
3,097.8
1,486.9
867.4
743.5
371.7
62.0
512
1,715.0
1,559.1
779.5
374.2
218.3
187.1
93.5
15.6
1024
858.4
780.4
390.2
187.3
109.3
93.6
46.8
7.8
1518
579.3
526.6
263.3
126.4
73.7
63.2
31.6
5.3
