10. Digital audio connector (4-1 pin SPDIF_OUT)
This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port.
Ensure that the audio device of Sound playback is Realtek High Definition Audio (the
name may be different based on the OS). Go to Start > Control Panel > Sounds and
Audio Devices > Sound Playback to configure the setting.
The S/PDIF module is purchased separately.
E2KM1I
-DELUXE
E2KM1I-DELUXE Digital audio connector
SPDIF_OUT
+5V
SPDIFOUT
GND
Chapter 1: Product introduction
1-22
